MP19-13 - Virtual Reality Immersion for Preoperative Planning and Education for Partial Nephrectomy

Saturday, September 22
2:00 PM - 4:00 PM
Location: Room 241

Introduction & Objective :

Surgeons rely on two-dimensional imaging using computed tomography (CT) or magnetic-resonance (MRI) to create a mental, three-dimensional (3D) understanding prior to surgery. Virtual reality (VR) technology immerses the user in an interactive 3D environment enabling manipulation of the pertinent anatomy. Herein, we evaluated VR models for preoperative planning and patient education prior to partial nephrectomy.

Methods : After IRB approval, using standard preoperative imaging (CT=13 and MRI=3) and 3D Slicer software, 16 VR models were created for viewing with a head-mounted display (Oculus Rift, Facebook Inc.) (Figure 1). Three expert surgeons (JL, KK, EU) evaluated their preoperative anatomical understanding (0 = poor; 10 = excellent) using CT alone vs. CT with VR. Additionally, surgeons and patients recorded their experience with the VR technology using a Likert-type scale (1=strongly disagree to 5=strongly agree).

Results : Pre-operatively, the VR model provided a significantly improved understanding of the location, size and shape of the renal mass, the optimal surgical approach, and the pertinent anatomy (i.e. vasculature, collecting system, hilar anatomy and ureteral location) compared to CT alone (p < 0.05) (Table 1). Surgeons strongly agreed (4.9/5, range 4-5) that the VR model improved understanding of the anatomy; they rated the VR model highly as a surgical planning tool (4.9/5, range 4-5) and an aid for teaching residents (4.9/5, range 4-5). In 56% of the cases, the surgical approach was altered based on the preoperative VR experience. The post-operative assessment correlated well with the surgical anatomy. The VR rendering improved patient understanding and comfort level regarding their surgery.

Conclusions : VR created 3D displays of renal anatomy prior to partial nephrectomy enhanced surgeons’ preoperative anatomical understanding and modified the surgical approach in over half of the cases. Additionally, the VR experience improved patient understanding of their impending surgery and reduced their preoperative anxiety.
