Building Structures- Case Studies & Concepts

Single Abstract

341358 - Innovation at Large, A Stadium Case Study

Friday, April 20
1:30 PM - 3:00 PM
Location: 203BC


The new Mercedes Benz Stadium, the home of the NFL's Atlanta Falcons and MLS's Atlanta United will feature a host of engineering innovations in its pioneering design. The 75,000 seat stadium features a 723' long span steel retractable roof with 8 moving petals that open like a camera lens in an optical illusion, where the petals appears to rotate, but uses standard equipment. This dramatic, unprecedented, movement opens the roof in less than 10 minutes. The moving petals cantilever up to 223' from the fixed roof, creating a 105,000 sf opening when opened. We will share the thought proceses behind this approach and how it was implemented.
The roof also supports at the center of its span, a 58' tall, 360-degree LED video scoreboard, the largest in sports. The scoreboard is supported along the sides of the trusses, integrated onto the structure, to allow uninterrupted views to the sky when the petals are open.
The geometrically complex facade is clad in single skin ETFE, a light weight and translucent material, its first use in the United States. The facades lean both towards and away from the building in large triangular facets, a move a away from the more typical curvilinear sports stadium facades.
The building is also on track to be the first LEED Platinum stadium. This presentation will focus on the innovative approach of the team in an effort to create a icon for Atlanta, as requested in the RFP. It will educate the participants on the various technology employed from the initial concept, to construction documents, through an atypical 3D approach checking over 50,000 3D steel shop drawings. The difficulties of innovation in large scale projects will be discussed, especially in light of the fast track schedule and a discussion of engineering solutions to the many challenges will be presented.
see the video at: http://mercedesbenzstadium.com/media/fly-mercedes-benz-stadium/

Erleen Hatfield

Founder
Hatfield Group

Erleen Hatfield, SE, AIA, LEED AP is a Partner of Buro Happold, a global multi-disciplinary engineering consulting firm, and is based in New York. She has over 25 years of experience in the structural design of a wide range of complex projects including sports facilities, high-rise and cultural buildings. She is both a licensed structural engineer and architect.

She frequently lectures on technology and innovation in the building design and construction industry. With a focus on integrated engineering and the use of innovative technology. She teaches at Yale University and is a past board member of numerous industry organizations, such as Applied Technology Council, Pankow Foundation, AIA Technology Committee and more.
